UK2.5B Screw Terminal Blocks Kit UK2.5N Modular DIN Rail Mounted Strips 32A 690V

Shenzhen Jetacon Technology Ltd

UK2.5B Screw Terminal Blocks Kit UK2.5N Modular DIN Rail Mounted Strips 32A 690V

Brand Name : Jetacon

Model Number : UK2.5B Modular

Certification : UL, CE

Place of Origin : Guang Dong

MOQ : 10 pieces

Price : US $2.99

Payment Terms : T/T, L/C, Paypal, Payoneer

Supply Ability : 1KK poles monthly

Delivery Time : 7-20 working days

Packaging Details : Standard Export Carton

Number : 5 - 30 pieces

Conductor Size : 11 - 20 AWG

Type : Screw

Contact Now

-
Model Number UK 2.5B
Color Grey, Blue, other color can be customized
Length / Height / Wide (mm) 42.5mm / 41mm /6.2mm
Connection method Screw connection
Material Nylon PA66
Rated Voltage/Current 690V/32A
Cross section, solid/soft Cable 0.2-4 mm² / 0.2-2.5 mm²
Conductor Size 24-12 AWG
Mounting Type NS 35/7.5
Standard IEC 60947-7-1
LOGO Customized logo are supported
Packing Detail 6.9g/pc, 50pcs/BOX, 3000pcs/ carton
Certification CE/RoHS/CQC/ISO 9001
-
-
Model Hard Wire
(mm2)
Soft Wire
(mm2)
Rated
Current
(A)
Rated
Voltage
(V)
Dimension
(mm)
UK2.5B 0.2-4 0.2-2.5 32 690 6.2 x 42.5 x 42
UK3N 0.2-4 0.2-2.5 32 800 6.2 x 42.5 x 42
UK5N 0.2-6 0.2-4 41 800 6.2 x 42.5 x 47
UK6N 0.2-10 0.2-2.5 57 800 6.2 x 42.5 x 47
UK10N 0.5-16 0.5-10 76 800 10.2 x 42.5 x 47
UK16N 2.5-25 4-16 101 800 12.2 x 42.5 x 54
UK35N 0.75-50 0.75-35 150 1000 15.2 x 50.0 x 62
UKH50 16-50 25-50 150 1000 20 x 70.5 x 83.5
UKH95 25-95 35-95 232 1000 25 x 83 x 97.5
UKH150 35-150 50-150 309 1000 31 x 100 x 118.5
USLKG2.5 0.2-4 0.2-2.5 32 / 6.2 x 42.5 x 42
USLKG3 0.2-4 0.2-2.5 32 / 6.2 x 42.5 x 47
USLKG5 0.2-6 0.2-4 41 / 6.2 x 42.5 x 47
USLKG6N 0.2-10 0.2-6 57 / 8.2 x 42.5 x 47
USLKG10N 0.5-16 0.5-10 76 / 10.2 x 42.5 x 47
USLKG16N 2.525 4-16 101 / 12.2 x 42.5 x 54
USLKG35N 0.75-50 0.75-35 150 / 15.2 x 50.0 x 62
USLKG50 16-50 25-50 150 / 20 x 70.5 x 81.5
